PCB Data Integration SDK.
Remove the friction of moving PCB data between ECAD, MCAD and CAE tools.
Our PCB Data Integration SDK saves you modeling time with PCB substrate and assembly support and enables enterprise collaboration
One SDK for all your ECAD conversion needs
Our Data Integration SDK for PCB turns heterogeneous ECAD formats into a clean, neutral data model:
- Unified ECAD parsing for IDF, IDX, ODB++, IPC2581 and more.
- Consistent JSON output ready for CAD, PLM or simulation pipelines.
- Cloud-ready REST API and native C++ services.
- Built-in comparison and validation services for design iterations.
Proven PCB technology for collaboration
Allow various designers or analysts to access key engineering PCB parameters outside of traditional tools.
- Scales from desktop utilities to enterprise PLM integrations.
- Backed by flexible data storage options (file system, NoSQL or Dataset Storage Service).
Easy ECAD data extraction and normalization
Access all the PCB information you need through one configurable interface.
Bring in layout and manufacturing data with a single call:
- Standard API for reading and comparing ECAD files.
- Normalized stack-up, components, holes, nets and restrictions in one schema.
- Configurable filters to control fidelity and performance.
- Ready for automation in CI/CD or batch conversion workflows.
Personalized deployment options
Embed our PCB Data Integration SDK in your product or internal platform, tailored to your environment:
- Ship as C++ DLLs or as a containerized REST service.
- Deploy on-premise, in private cloud or public cloud via Docker images.
- Configurable to match customer-specific formats, versions and naming conventions.
- Neutral, extensible data model designed to grow with new formats and use cases.
Features
Deliver robust, maintainable integrations with:
- .NET support
- RESTful API
- Highly configurable behavior
- Swagger documentation
- Health monitoring
- Docker container deployment
